2000A AC / DC TRMS Clamp-On Multimeter with VFD EF-Detection & PC Interface

Special Features:
<br>
• AutoCheck Voltage &amp; Ohms<br>
• VFD-V &amp; VFD-HZ function<br>
• 5ms CREST-MAX capture mode (Peak Hold)<br>
• Autoranging Relative -Zero mode<br>
• Display Hold function<br>
• EF-Detection (NCV)<br>
• Backlight LCD Display<br>
• Auto Power Off<br>
• Diode Test &amp; Continuity Test<br>
• PC Interface (Optional)
<br><br>
<strong class="header-red-small">General Specifications </strong> <br>
• <strong>Sensing :</strong> TRMS sensing<br>
• <strong>Jaw Opening :</strong> 55mm max.<br>
• <strong>Display : </strong>3-5/6 digits 6000 counts &amp;<br>
  3½ digits 1,999 counts for Hz.<br>
• <strong>Update Rate :</strong> 5 per second nominal<br>
• <strong>Polarity :</strong> Automatic<br>
• <strong>Low Battery :</strong> Below approx 2.4V<br>
• <strong>Operating Temperature :</strong> 0 °C to 40 °C<br>
• <strong>Relative Humidity :</strong> Maximum 80% R. H.<br>
  for temperature upto 31 °C decreasing linearly<br>
  to 50% Relative Humidity at 40 °C<br>
• <strong>Storage Temperature :</strong> -20 °C to 60 °C,<br>
  &lt; 80% R.H. (With battery removed)<br>
• <strong>Altitude :</strong> Operating below 2000m<br>
• <strong>Temperature Coefficient :</strong> nominal 0.15 x (specified accuracy) / <br>
  °C @ (0 °C - 18 °C or 28 °C- 40 °C), or otherwise specified<br>
• <strong>Power supply :</strong> Standard 1.5V AAA Battery x 2.<br>
• <strong>Power Consumption :</strong> Typical 14mA for Current function,&amp; 5.2mA for others.<br>
• <strong>APO Timing :</strong> Idle for 34 minutes<br>
• <strong>APO Consumption :</strong> 10 µA typical<br>
• Dimension : 264(L) x 97(W) x 43(H) mm<br>
• Weight : Approx. 608gm.<br>
