1 Phase & 3 Phase Harmonics TRMS Power Clampmeter With PCInterface
Model: KM 2746
Make: Kusam-Meco
Special Features:
<br>
<br>
• <b>Sensing:</b> AC & AC+DC True RMS <br>
• <b>Jaw Opening & Conductor Diameter:</b> 51mm MAX <br>
• <b>Altitude:</b> Operating below 2000m <br>
• <b>Operating Temperature:</b> -10 °C to 50 °C <br>
• <b> Relative Humidity:</b> Maximum relative humidity 80% for temperature up to 31 °C <br>
decreasing linearly to 50% relative humidity at 50 °C <br>
• <b>Storage Temperature:</b> -20 °C to 60 °C < 80% R.H. (with battery removed) <br>
• <b>Temperature Coefficient:</b> nominal 0.15 x (specified accuracy)/ °CC @ (-10 °C <br> 18°C or 28 °C - 50 °C), or otherwise specified <br>
• <b>Low Battery:</b> Below approx. 2.5V <br>
• <b>APO Timing:</b> Idle for 30 minutes <br>
• <b> APO Consumption:</b> 25uA typical <br>
• <b>Power Supply:</b> 1.5V AA Size (IEC LR6) battery X 2 <br>
• <b>Power Consumption:</b> Typical 33mA for Current & Power functions, and 22mA for others <br>
• <b>Dimension:</b> Approx. 258(L) X 94(W) X 44(H)mm <br>
• <b>Weight:</b> Approx. 394 gm <br>
• <b>Accessories :</b> Test leads (pair), Battery, User’s manual & Carrying case <br>
